Shockwave therapy devices

Place of Origin: Shaanxi,China
Model Number: MKYLB-100
Type: Rehabilitative Devices
Material:ABS Plastic
Function: Treat various chronic pain
Dimention:500mm(L)*442mm(W)*193mm(H)
N.W：15.8kg
G.W: 18.8kg
Package Dimention: 620mm*610mm*320mm
Certification: ISO9001, ISO13485

Send Inquiry

Product Description

Introduction

At Shaanxi Miaokang Medical Technology Co.,ltd., we are undaunted in our interest to reform the scene of outer muscle torment the board and recovery. Our front line pneumatic ballistic extracorporeal shockwave treatment gadget (ESWT) remains as a demonstration of our commitment and development. This cutting edge innovation not just offers patients a painless, successful, and safe treatment choice yet in addition tends to the limits of conventional strategies, which frequently include obtrusive medical procedures or extensive recuperation periods.

Our ESWT gadget uses complex air pressure innovation to convey exact, controlled shockwaves to designated regions. These shockwaves infiltrate profoundly into the tissues, invigorating cell recovery and actuating the body's regular mending instruments. This outcomes in huge relief from discomfort, diminished irritation, and further developed scope of movement, empowering patients to continue their day to day exercises effortlessly and solace.

Besides, our Shockwave therapy devices is planned in light of patient solace and accommodation. Its easy to understand interface and natural controls guarantee that medicines are directed flawlessly and effectively. Also, our gadget is outfitted with cutting edge security includes that limit the gamble of intricacies and incidental effects, furnishing patients with inner serenity all through the treatment interaction.

At Shaanxi Miaokang Clinical Innovation Co., Ltd., we are focused on conveying the best clinical arrangements that enable patients to beat their aggravation and recover their portability. Our pneumatic ballistic extracorporeal shockwave treatment gadget addresses a critical step in the right direction in the field of outer muscle torment the board and restoration, and we are pleased to offer it to patients around the world.

Product Features

Our Shockwave therapy devices have many features:

Host and Trolley Options: Choose between the standalone host or the complete set with a trolley for enhanced mobility and convenience.

Stepless Frequency Conversion: Adjust frequency seamlessly to suit various treatment needs.

Real-time Pressure Monitoring: Ensures that each treatment is delivered with optimal intensity and precision.

Pressure and Frequency Adjustment: Tailored treatment settings to meet the specific needs of each patient.

Compact and Lightweight Design: With a weight of only 15.8 kg (excluding trolley), this device is easy to maneuver and store.

Equipment Parameters

Parameter	Specification
Power Supply	AC 220V 50Hz
Input Power	150W
Fuse	F3.15AL250V
Electric Shock Protection Type	Class I
Electric Shock Protection Degree	Type B
Waterproofing Grade	Not Applicable
Operation Mode	Intermittent Loading, Continuous Operation
Working Pressure	150kPa~400kPa
Energy Density	0mJ-0.41mJ/m㎡
Penetration Depth	0mm~26mm
Operating Frequency	1Hz~16Hz
Impact Times	1000 times~9000 times
Number of Treatments	2-5 times
Treatment Cycle	2-4 days
Ambient Temperature (Operating)	+10°C~+30°C
Relative Humidity (Operating)	30%~75%
Atmospheric Pressure (Operating)	700 hPa~1060 hPa
Ambient Temperature (Storage)	-40°C~55°C
Relative Humidity (Storage)	≤90%
Atmospheric Pressure (Storage)	700 hPa~1060 hPa
Weight	15.8kg (excluding trolley)

Working Principle

The Shockwave therapy devices operates by compressing air through an air compressor. The energy generated propels a bullet body in the control handle, causing it to impact the treatment head. This impact generates shockwaves, which are then transmitted through the treatment head to the affected areas, providing targeted pain relief and promoting recovery.

Application

Our device is exceptionally versatile and can be used in various departments including Orthopedics, Rehabilitation Medicine, Sports Medicine, and more. It is particularly effective in treating conditions like plantar fasciitis, tennis elbow, and shoulder periarthritis.

product-1-1

Why Choose Us

Shaanxi Miaokang Medical Technology is recognized as a "national high-tech enterprise" and holds numerous patents and certifications. Our commitment to innovation, quality, and customer satisfaction makes us a leader in the medical technology industry.

Certifications

Our Shock Wave Therapy Device complies with relevant industry standards and boasts 11 utility model and appearance patents, 8 software works, 7 registered trademarks, and 3 medical product registration and production licenses.Obtained ISO13485,ISO9001.

product-1-1

FAQ

How often can the device be used?

The device can be operated intermittently and is suitable for continuous use, allowing for flexibility in treatment schedules.

What safety features does the device have?

It includes Class I electric shock protection and Type B protection degree, ensuring safety for both the operator and the patient.

Contact Us

For more information on our shockwave therapy devices or to place an order, please contact us at cathy@miaokang.ltd. We are ready to assist you with any inquiries and provide further details on our products and services.

Our focus on technological innovation and comprehensive after-sales service ensures that our medical devices not only meet but exceed the rigorous demands of modern medical institutions. Choose Shaanxi Miaokang Medical Technology for reliable, effective, and innovative solutions in medical care and rehabilitation. Contact us today to see how we can help enhance your clinical outcomes and patient satisfaction.
